DuraNAS 1000

Rugged Network Attached Storage (NAS) - IP65, EN50155

The DuraNAS 1000 is a reliable high capacity Network Attached Storage (NAS) for Rolling Stock and for any application that requires a rugged device.

Download datasheet download

Seleziona un formato

A4 letter

Caratteristiche

Simple and Versatile - Ready-to-use Network Attached Storage for applications such as remote storage, networked video recording and many more
Power over Ethernet - Cuts installation cost and time with a single cable PoE connection
Quick and Easy Setup - Intuitive Web GUI for system configuration
EN50155 Fully Qualified - Fully compliant with EN50155 for Railway installations
Rugged for Harsh Environments - Designed to withstand mechanical, electrical and environmental stress typical of harsh environments

Descrizione

The DuraNAS 1000 is a reliable high capacity Network Attached Storage (NAS) for Rolling Stock and for any application that requires a rugged device.

Featuring two HDD/SDD units, it can be configured as a single aggregated volume or as a RAID 1 volume. A safe shutdown capability ensures that buffered data is written even in the case of a sudden power loss.

The unit is configured through an easy to use Web GUI: system setup and storage management can all be done through an intuitive visual interface.

A 10/100Mbps Power over Ethernet (POE) connector provides a convenient interface that allows a single cable (power and data) installation. Two mounting options offer great deployment flexibility: brackets for permanent positioning, or a key-locked sledge for use cases where the device needs to be quickly removed.

The DuraNAS 1000 is EN50155 certified and comes with wide operating temperature range, an IP65 ingress protection and a very sturdy enclosure with a circular connector, making it suitable for harsh environments.

For customers requiring more configuration flexibility, Eurotech Professional Services offer an extensive number of options, including custom front panel/connectors, branding and additional certifications.

Ordering code: NAS-1000-xx
XX -10 -11 -20 -21
STORAGE Capacity 2x 1TB (HDD) 2x 1TB (SSD)
RAID RAID 1 or Large Single Volume Mode
Encryption Advanced Encryption Standard (AES); 128 bit key-size
Safe Shutdown Yes
I/O INTERFACES Ethernet 1x 10/100Mbps - M12 Connector
OTHER LEDs 1x Ethernet Link; 1x Ethernet Activity; 1x SATA Boot Failure; 1x Early On; 1x Power On; 1x CPU Power On
POWER Input Power-over-Ethernet (PoE) 37 – 57VDC Powered Device Class 0 Power Classification (IEEE 802.3af Compliant)
Consumption < 12W
ENVIRONMENTAL Operating Temp. EN50155 OT1 ST1 -25 to +55°C (+70°C for 10’) (HDD not powered below -10 °C) EN50155 OT3 ST1 -25°C/+70°C (+85°C for 10’)
Storage Temp. - 40 to +85°C
Humidity 95% Relative Humidity non Condensing
CERTIFICATIONS Regulatory 2014/30/UE (CE EMC)
Safety EN 60950 (Safety)
Vertical EN 50155 (Railway Applications); EN 61373 (Vibrations & Shocks); EN 61000 (Immunity, Emission); EN 60068 (Environmental Testing); EN45544 HL3 (Railway Applications – Fire Behaviour)
Ingress IP65
MECHANICAL Mounting Style Fixed, with Brackets Removable, Dock with Key Lock Fixed, with Brackets Removable, Dock with Key Lock
Dimensions (WxHxL) 171x59.5x285mm 171x83x293mm 171x59.5x285mm 171x83x293mm
Weight < 3Kg

Download

DuraNAS 1000 Datasheet
PDF download

Seleziona un formato

A4 letter
mail
richiesta informazioni
* campi obbligatori
Letta e compresa l'informativa sulla privacy *
Consenso a ricevere e-mail di marketing * - leggi
Vorremmo condividere con te le nostre comunicazioni di marketing. Rimani aggiornato sugli ultimi prodotti, eventi e newsletter di Eurotech dando il tuo consenso a ricevere le nostre e-mail di marketing. Se vuoi sapere di più su come gestiamo i tuoi dati e su come aggiornare le tue preferenze di iscrizione, consulta qui la nostra Informativa sul Trattamento dei Dati Personali
Premi “INVIA” per confermare i dati e inviare la richiesta. Premi “ANNULLA” per resettare i campi

Highlights

  • • Ruggedized for Harsh Environments
  • • Up to 1TB Aggregated Storage
  • • RAID 1 Functionality
  • • 10/100Mbps Ethernet with POE
  • • EN50155 Fully Qualified
  • • Quick and Easy Setup
