The Advme1209A is a 64-point Digital input board. Input is divided between eight input channels with a common for every eight points using different power supplies.
Photo-coupler isolation
Photo-coupler isolation is provided between input channels and between input channel and the VME bus. High speed photo-coupler supports fast input.
Other features:
Interrupt can be issued to one of the VME interrupt request lines from *IRQ1 to *IRQ7.
A switch on the front panel allows to select each group of 8 inputs in order to display them by LEDs.
A device driver for VxWorks and a sample program are optionally available.

Architecture:

• VME compliant

Digital Input:

• 8 channels
• Input voltage: 12 to 24V DC
• Input current: 6.7mA typical (24V DC)
• Input connector: two MIL-type 40-pin headers

Isolation:

• Method: photo-coupler isolation (delay time: 2µs typical)
• Withstanding voltage between input and system: 1500V AC for one minute
• Withstanding voltage between input and channels: 1500V AC for one minute

Interrupt:

• Can be set 8 point interrupt inpt using DIO to 7

LED display:

• LED display of input values for every eight points

Bus:

• VME bus
• Width complies with A16 D16/D08 (EO) Rev.C.3
• Accessible using AM codes 29H and 2DH

Power Supply:

• Single +5V DC

Power Consumption:

• 20W typical

Mechanical:

• Dimensions: 6U – 262 x 172 mm (10.31” x 6.77”)
• Pitch: Single slot – 20.02 mm (0.79”)
• Weight: 240g typical

Operating Systems Supported:

• VxWorks®

* E-041 DIO Monitor Tool
