AIM104-ADC16-IN8

PC/104 Module with Opto-Isolated 16-channel 12-bit ADC, Opto-Isolated 8-channel Digital Inputs

The AIM104-ADC16-IN8 is an 8-bit PC/104 module providing eight opto-isolated digital inputs and sixteen single ended or eight differential analogue input. A 1000V isolation is provided between the PC/104 system and the electrical system under control.

HIGHLIGHTS

  • 12-bit ADC inputs, link-selectable as either 16 single-ended or 8 differential channels
  • 8 opto-isolated digital inputs
  • All digital inputs include a fixed 10ms input debounce filter
  • Maximum acquisition rate: 2000 conversions/sec
  • Module access LED

APPLICATIONS

  • Industrial
  • Medical
  • Transportation
  • Defense
The AIM104-ADC16-IN8 is an 8-bit PC/104 module providing eight opto-isolated digital inputs and sixteen single ended or eight differential analogue input.
Isolation
A 1000V isolation is provided between the PC/104 system and the electrical system under control. Isolation between adjacent channels is limited by the wiring and the connectors to 30V. All digital inputs include a fixed 10ms debounce filter.
