A complete choice of processors allows for the optimization between price and performance.
4 USB (2.0) interfaces and 2 Gigabit Ethernet ports allow the connection of a vast range of devices.
There can be either 3 RS232 serial ports or 4 if the parallel port is not required.
For embedded applications are available different options such as the compact Flash and the XPE® operating system.

Processor

• Intel Celeron M 440 1,86 GHz - FSB 667 MHz-1MB cache
• Intel Core Duo 2,0 GHz - FSB 667 MHz-2MB cache
• Intel Celeron P4500 1,86 GHz - FSB 800/1066 MHz-2MB cache
• Intel i5 520M 2,4 GHz – FSB 800/1066 MHz-3 MB cache
• Intel i7 620M 2,66 GHz – FSB 800/1066 MHz-4 MB cache
• Intel® Celeron M™ 600 MHz (contact us)
• Intel® Celeron M™ 1,5 GHz (contact us)
• Intel® Pentium M™ 1,8 GHz (contact us)

Memory

• 512MB to 8GB (P4500, i5, i7-DDRIII)

Interfaces

• 2x K/M PS2
• 3x RS-232
• 4x USB 2.0
• 2x Ethernet 10/100/1000
• VGA
• Audio

SSD Flash Disk

• CF Type I socket

Hard Disk

• 2.5" SATA

Mounting

• Wall mount – optional DIN rail mounting

Power Supply

• 115-230 V/AC 50-60 Hz (24 V/DC optional)

Dimension

• 245 x 233 x 88 mm (9.65" x 9.17" x 3.46")
• Weight: about 3.5kg

Operating Temperature

• 0 to +45°C

Relative Humidity

• 10% to 90% non condensing

Operating Systems Supported

• Windows XP Embedded®
