Advme1209A

64 channel high-speed digital input VME board

The Advme1209A is a 64-point digital input board. Photo-coupler isolation is provided between input channels and between input channels and the VME bus.

Not Recommended for New Design

HIGHLIGHTS

  • Photo-coupler isolation
  • 64-point input divided in eight channels
  • Can be set eight point interrupt input

APPLICATIONS

  • Industrial
  • Medical
  • Transportation
  • Defense
FeaturesSpecificationsAccessories

The Advme1209A is a 64-point Digital input board. Input is divided between eight input channels with a common for every eight points using different power supplies.
Photo-coupler isolation
Photo-coupler isolation is provided between input channels and between input channel and the VME bus. High speed photo-coupler supports fast input.
Other features:
Interrupt can be issued to one of the VME interrupt request lines from *IRQ1 to *IRQ7.
A switch on the front panel allows to select each group of 8 inputs in order to display them by LEDs.
A device driver for VxWorks and a sample program are optionally available.
