The Adbc8031 from Eurotech combines the graphics and performance capabilities of the Intel® Core i7™ processor and delivers it in a low-power COM Express standard. Targeted for applications such as automotive, controls, gaming, digital signage, and more, the Adbc8031 offers hyper-threading technology to run multiple processes concurrently for extensive data-crunching capabilities while maintaining a low power specification. In addition, the Adbc8031 is ideal for devices where security and reliability are critical. It is equipped with an Advanced Encryption Standard (AES) engine and has Error Correction Code (ECC)-supported memory to help detect and correct errors in memory transactions for mission-critical applications.
Customization
The Adbc8031 supports Windows 7, Windows XP, WES 2009, and Wind River Linux, offering OEMs a comprehensive list of operating systems for their application needs. Furthermore, Eurotech offers its top-notch design expertise in working with designers to develop and support custom carrier boards.

Architecture:

• COM Express

CPU:

• Intel® Core i7-620E™/Intel® Core i7-620LE™/ Intel® Core i7-620UE™ processor (optional at shipment)

Chipset:

• Mobile Intel® QM7™ Express Chipset

Memory:

• DDR3-800: up to 2GB with ECC support
• SPI- Flash Boot ROM 4GB
• 4x SATA ports (SATA/3000)

Graphics/Video/Audio:

• 1x SVDO port
• 1x LVDS port

USB:

• x8 USB 2.0 ports

Ethernet:

• 1x 10/100/1000 BASE-T port

Other Interfaces:

• 1x LPC port
• 1x SMBus
• 1x IC2

Bus:

• 1x PCI, 32 bit, 33MHz, 3.3V
• One PCI Express Graphics port x16 lane (or two x8 lanes)
• Four PCI Express port x1 lanes (or one port x4 lanes)

Power Supply:

• +12V DC
• +5V DC
• +3V DC

Power Consumption:

• 18W to 35W

Mechanical:

• Dimension: 125 x 95 mm (4.92” x 3.74”)
• Width: 16.8 mm (0.66”)

Operating Temperature:

• 0 to 60°C (standard)

Operating Systems Supported:

• Windows 7®, Windows XP®, WES 2009®, Wind River Linux®
